Flip boost module

Flip boost

80.00€

A dual amplified attenuverter.

Categories: , Tags: , , , ,

Description

Flip boost is a 4HP dual attenuverter + amplifier.

Each channel has a potentiometer to adjust the attenuverter, and a switch to toggle between unity gain and boosted gain (amplification factor can be adjusted behind the module with a trimmer).

Flip boost can be used to amplify audio signals too !

Input 1 is normalled to input 2, and when nothing is patched on input 1, an arbitrary default voltage is applied (typically 5V, but adjustable between -12V and +12V, with a trimmer behind the module).

Features

  • Two amplified attenuverters.
  • Post-attenuverter amplification is enabled/disabled with a “boost” switch.
  • The two gains are adjustable with trimmers behind the module
  • Input 1 is normalled to 5V (adjustable)
  • Input 2 is normalled to input 1.

Technical specs

  • Size: 4 hp
  • Depth: 30 mm (including power connector)
  • Power consumption:
    • +5V: 0mA
    • +12V: 15mA
    • -12V: 15mA

User manual

TBD
